| Numéro d'article | AM-1024600L3HMQW-00H |
| Marque | AMPIRE |
| Taille | 10.1 |
| application | Industrial Automotiv |
| Résolution | 1024×600 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 500:1 |
| Couleurs | 262K |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AMPIRE |
| modèle | AM-1024600L3HMQW-00H |
| taille diagonale | 10.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1024(RGB)×600 [WSVGA] 117PPI |
| configuration | RGB Vertical Stripe |
| zone active | 222.72(H)×125.28(V) mm |
| contour sombre. | 235(H)×145.8(V) ×8.85(D) mm |
| zone de lunette | - |
| traitement | Antiglare |
| luminosité | 550 cd/m² (Typ.) |
| Rapport de contraste | 500:1 (Typ.) (TM) |
| direction de la vue | - |
| Temps de réponse | 4/12 (Typ.)(Tr/Td) |
| angle de vue | 70/70/70/50 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 262K 47% NTSC |
| Source de lumière | WLED [6S6P] , 30K hours , With LED Driver |
| lester | TBD |
| conçu pour | Industrial Automotive Display |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-1024600-070H | Other | 7.0 | 1024×600 |
| AM-1024600KTMQW-01H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600KTMQW-04H | AMPIRE | 7.0 | 1024×600 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AM-1024600L7TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| B101XAN01.3 | AUO | 10.1 | 1366×768 |
| LP101WSA-TLN1 | LG Display | 10.1 | 1024×600 |
| M101MWW4 R0 | IVO | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
