| Numéro d'article | AM-1024600L2HMQW-T01H |
| Marque | AMPIRE |
| Taille | 10.1 |
| application | Industrial |
| Résolution | 1024×600 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 500:1 |
| Couleurs | 262K |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AMPIRE |
| modèle | AM-1024600L2HMQW-T01H |
| taille diagonale | 10.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1024(RGB)×600 [WSVGA] 117PPI |
| configuration | RGB Vertical Stripe |
| zone active | 222.72(H)×125.28(V) mm |
| contour sombre. | 235(H)×145.8(V) ×9.8(D) mm |
| zone de lunette | 225.92(H)×128.48(V) mm |
| traitement | - |
| luminosité | 800 cd/m² (Typ.) |
| Rapport de contraste | 500:1 (Typ.) (TM) |
| direction de la vue | - |
| Temps de réponse | 4/12 (Typ.)(Tr/Td) |
| angle de vue | 70/70/70/50 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 262K 47% NTSC |
| Source de lumière | WLED [6S6P] , 50K hours , With LED Driver |
| lester | TBD |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | 4-wire Resistive Touch |
| type d'interface | LVDS (1 ch, 6-bit) , 30 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -5 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
