| Numéro d'article | AM-1024600K7TMQW-T19H |
| Marque | AMPIRE |
| Taille | 7.0 |
| application | Industrial |
| Résolution | 1024×600 |
| Composition | a-Si TFT-LCD , LCM |
| Luminosité | |
| CR | 700:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | |
| marque | AMPIRE |
| taille diagonale | 7.0 inch |
| format pixel | 1024(RGB)×600 [WSVGA] 169PPI |
| zone active | 153.6(H)×90(V) mm |
| luminosité | 425 cd/m² (Typ.) |
| direction de la vue | 6 o'clock |
| angle de vue | 75/75/70/75 (Typ.)(CR≥10) |
| couleur de soutien | 16.7M |
| lester | TBD |
| fréquence d'images | 60Hz |
| modèle | AM-1024600K7TMQW-T19H |
| taper | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| contour sombre. | 165.5(H)×104.44(V) ×10.81(D) mm |
| Rapport de contraste | 700:1 (Typ.) (TM) |
| Temps de réponse | 20/20 (Typ.)(Tr/Td) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| Source de lumière | WLED [5S3P] , 30K hours , With LED Driver |
| conçu pour | Industrial |
| Ecran tactile | PCAP |
