| Numéro d'article | AM-1024600DTZQW-TA6H |
| Marque | AMPIRE |
| Taille | 7.0 |
| application | Industrial Outdoor H |
| Résolution | 1024×600 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | AMPIRE |
| modèle | AM-1024600DTZQW-TA6H |
| taille diagonale | 7.0 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 1024(RGB)×600 [WSVGA] 170PPI |
| configuration | RGB Vertical Stripe |
| zone active | 154.221(H)×85.92(V) mm |
| contour sombre. | 164.9(H)×128(V) ×12.6(D) mm |
| luminosité | 850 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | Symmetry |
| Temps de réponse | 13/15 (Typ.)(Tr/Td) |
| angle de vue | 85/85/85/85 (Typ.)(CR≥10) |
| mode de fonctionnement | IPS, Normally Black, Transmissive |
| couleur de soutien | 16.7M 58% NTSC |
| Source de lumière | WLED , 50K hours , With LED Driver |
| lester | - |
| conçu pour | Industrial Outdoor High Brightness |
| fréquence d'images | 60Hz |
| Ecran tactile | PCAP |
| type d'interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
