| Numéro d'article | AC121SA04 |
| Marque | Mitsubishi |
| Taille | 12.1 |
| application | Industrial |
| Résolution | 800×600 |
| Composition | a-Si TFT-LCD, LCM |
| Luminosité | |
| CR | 800:1 |
| Couleurs | 262K/16.7M |
| Rétroéclairage | WLED |
| Interface | LVDS |
| marque | Mitsubishi |
| modèle | AC121SA04 |
| taille diagonale | 12.1 inch |
| taper | a-Si TFT-LCD, LCM |
| format pixel | 800(RGB)×600 [SVGA] 82PPI |
| configuration | RGB Vertical Stripe |
| zone active | 246(H)×184.5(V) mm |
| contour sombre. | 260.5(H)×203(V) ×10(D) mm |
| zone de lunette | 249.0(H)×187.5(V) mm |
| traitement | Antiglare, Hard coating (3H) |
| luminosité | 500 cd/m² (Typ.) |
| Rapport de contraste | 800:1 (Typ.) (TM) |
| direction de la vue | 6 o'clock |
| Temps de réponse | 10/15 (Typ.)(Tr/Td) |
| angle de vue | 80/80/60/80 (Typ.)(CR≥10) |
| mode de fonctionnement | TN, Normally White, Transmissive |
| couleur de soutien | 262K/16.7M 72% NTSC |
| Source de lumière | WLED , 70K hours , With LED Driver |
| lester | 580g (Typ.) |
| conçu pour | Industrial |
| fréquence d'images | 60Hz |
| Ecran tactile | Without |
| type d'interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| source de courant | 3.3V (Typ.) |
| environnement | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
